A simple model visualizing the Moon’s orbit around the Earth and the lunar phases based on its position relative to the Earth and Sun.

Print Settings : Default Ender3 V3 KE Hyper PLA Settings, with "Overhang Optimization (Beta)" Enabled under Quality (Advance Parameters)

Assembly

What you will need :

- All 3D Printed Parts

- LED, Resistor, Power Source or any Light Source (Optional)

Steps :

0.1. Put 5mm LED Light inside the bigger Sphere (Sun)

0.2. Route the wire through the hole in Sun Sphere's peg and wire it up

1. Place the Sun's peg in the bigger hole in the Base Plate

2. Put the Moon's peg (smallest sphere) through the hole in arm of the Earth peg sleeve

3. Put the Earth's peg (2nd biggest sphere) through the Earth peg sleeve

4. Place the Earth's peg in the smaller hole in Base Plate

Note : Top half of Spheres having little bit of defects is normal and intended if you're not using supports, shouldn't be too noticeable in practice with low lightning and LED. LED isn't necessary but recommended for this model to work, it's for clarity and visualization of sunlight's effect on the Moon phase and the Earth.

Made for Creality Cloud "STEAM Education - Astronomical Planet Design Contest". Thanks you for checking this out, made with love <3

Update 1 : Increased Base Plate length to make lights look more accurate-ish.

Moon Phases Orbit Model

0.2mm layer, 2 walls, 15% infill

0.2mm layer, 2 walls, 15% infill
